Chapter 4 Configuration
Installation and Operation Manual
4-12
Configuring IPmux-11 for Operation
IPmux-11 Ver. 2.00
Channel 4
External
Fall back clock (Fall back clock type):
Internal
Adaptive
Rx clock
None
Fall back source (Fall back clock source):
Channel 1
Channel 2
Channel 3
Channel 4
External
3. Type S to save your changes.
Configuration>System>System clock
1. Master clock > (Rx clock )
2. Master source > (External )
3. Fall back clock > (Adaptive )
4. Fall back source > (Channel 1 )
>
Please select item <1 to 4>
S - save
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-12. System Clock Menu
