Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Additional Tasks 4-31
Sequence errors – total number of sequence errors occurred on the bundle
Jitter buffer underflows – total number of jitter buffer underflows occurred
on the bundle
Jitter buffer overflows – total number of jitter buffer overflows occurred on
the bundle.
Sequence Errors, Jitter Buffer Underflows and Jitter Buffer Overflows descriptions are
given in Chapter 6.
Monitoring>Status>Connection
Destination IP address: (1.1.1.1)
Next hop MAC address: (000000000000)
Connectivity status: > (OK)
Sequence errors: (0)
Jitter buffer underflows: (0)
Jitter buffer overflows: (0)
1. Bundle ID[1 – 1] ... (1)
>
R - reset counters
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-33. Connection Screen
Displaying the System Clock Information
You can view the status of the active system clock.
To display the system clock status:
• From the Status menu, select System clock.
Monitoring>Status>System clock
Active clock > (Adaptive)
> (Channel 1)
ESC-prev.menu; !-main menu; &-exit
Figure 4-34. System clock status screen
Transferring Software and Configuration Files
Software and configuration files can be transferred using TFTP.
To transfer a file using TFTP:
1. From the Utilities menu, select File Utilities.
Note
