Chapter 4 Configuration Installation and Operation Manual
4-2 Configuring IPmux-11 for Management IPmux-11 Ver. 2.00
4.2 Configuring IPmux-11 for Management
The IPmux-11 management software allows you to perform the following:
• Defining IP parameters of the IPmux-11 host
• Configuring management access
• Configuring control port parameters
• Setting the date and time
• Configuring the system clock
• Resetting IPmux-11 to the default values.
IPmux-11 system parameters are configured via System menu.
To access System menu:
1. From the Main menu, select Configuration.
The Configuration menu is displayed.
2. From the Configuration menu, select System.
The System menu appears (see Figure 4-1 ).
Configuration>System
1. Host IP >
2. Management >
3. System clock >
4. Control port >
5. Date/Time >
6. Factory default >
>
Please select item <1 to 6>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-1. System Menu
Configuring IP Host Parameters
IPmux-11 can be managed by a network management station, which is located on
the LAN connected to the one of the unit’s Ethernet ports. In order to establish a
proper connection, it is necessary to configure the following: host IP address,
subnet mask, default gateway, its trap, read and write communities. In addition,
you can enable or disable DHCP client of the device.
Configuring DHCP Client
To facilitate integration of a new device into a DHCP IP network, if no IP address
has been manually configured, IPmux-11 automatically requests one from the
DHCP server upon booting. IPmux-11 is shipped with the DHCP client set to
Enable
.
