Chapter 6 Troubleshooting and Diagnostics Installation and Operation Manual
6-22 Frequently Asked Questions IPmux-11 Ver. 2.00
Diagnostics>Trace route
1. Destination IP address ... (0.0.0.0)
2. VLAN tagging (Enable)
3. VLAN ID[1 - 4095] ... (1)
4. VLAN priority tag [0 - 7] ... (0)
5. Trace route send
>
Please select item <1 to 5>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 6-18. Trace route Menu
6.6 Frequently Asked Questions
Q : How does the IPmux handle/propagate alarms on the TDM and Ethernet side?
A : The IPmux handles alarms on the TDM and Ethernet side in the following
manner:
TDM side alarms
Unframed mode:
In case of LOS (Loss Of Signal) on the local IPmux side, AIS will be sent
towards the IP side, and will then be transferred over the E1/T1 to the
remote TDM device.
All other alarms sent from the near-end TDM device (including information
on timeslot 0), will be propagated transparently by the local IPmux, to the
remote end TDM device (over the IP connection).
Framed mode:
In case of LOS/LOF/AIS detected on the local IPmux side, a user-configurable
conditioning pattern (00 to FF) will be sent on the relevant timeslots (over the IP
connection), to the far-end TDM device. A user-configurable conditioning
pattern can also be applied on the ABCD bits (CAS signaling 1 to F) going
towards the remote PBX.
The frame synch on the E1/T1 level is maintained in favor of the end TDM
devices.
Ethernet Side Alarms
Unframed mode:
In case of local failure on the IPmux, or a situation of jitter buffer
underflow/overflow, an (unframed) AIS will be sent towards the near-end TDM
side.
