1.4 Technical Specifications
E1 Interface Compliance ITU-T Rec. G.703, G.704, G.706, G.732, G.823
Data Rate 2.048 Mbps
Line Code HDB3
Framing Unframed, framed, multiframe; with or without CRC-4
Signaling CAS, CCS (transparent)
Line Impedance 120Ω, balanced; 75Ω, unbalanced
Signal Levels Receive: 0 to -36 dB with LTU (long haul)
0 to -10 dB without LTU (short haul)
Transmit pulse amplitude, balanced: ±3V ±10%
Transmit pulse amplitude, unbalanced: ±2.37V ±10%
Jitter Performance As per ITU-T G.823
Connector Balanced: RJ-45
Unbalanced: Two BNC coax (via an adapter cable)
T1 Interface Compliance ANSI T1.403, AT&T TR-62411, ITU-T Rec. G.703, G.704,
G.824
Data Rate 1.544 Mbps
Line Code B8ZS, B7ZS, AMI
Framing Unframed, SF, ESF
Signaling CAS (robbed bit), CCS (transparent)
Line Impedance 100Ω, balanced
Signal Levels Receive: 0 to -36 dB
Transmit pulse amplitude: ±3V ±20%; 0 dB, -7.5 dB,
-15 dB (CSU), user-selectable
±2.7V ±10%, 0 to 655 feet, (DSU), user-selectable
Jitter Performance As per AT&T TR-62411, G.824
Connector RJ-45
Ethernet
Interface Compliance IEEE 802.3, 802.3u, 802.1p&Q
Number of Ports Network: 1 (copper or fiber)
User: up to 2 (copper only)
Data Rate UTP: 10 Mbps or 100 Mbps, full or half-duplex
Fiber: 100 Mbps full-duplex
Frame Size 1536 bytes max (user port)
Fiber Optic
Specifications See Table 1-1
Connector LC, SFF-based
