Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Configuring IPmux-11 for Operation 4-23
Configuration>Connection>DS0 bundle
+1 +2 +3 +4 +5 +6 +7 +8 +9 +10
TS 0 1 0 0 0 0 0 0 0 0 0
TS 10 0 0 0 0 0 0 0 0 0 0
TS 20 0 0 0 0 0 0 0 0 0 0
TS 30 0
1. Change cell [0 - 1] ... (0)
>
Please select item <1 to 1>
E - Enable All; L - Disable All
ESC-prev.menu; !-main menu; &-exit; ?-Help 1 Mngr/s
Figure 4-20. DS0 Bundle Menu
Configuration>Connection>Bundle connection
TDM channel ID: 1 Bundle ID: 1
1. Destination IP address ... (0.0.0.0)
2. Next hop ... (0.0.0.0)
3. IP TOS[0 - 255] ... (0)
4. Connection status (Enable)
5. Destination bundle[1 - 8063] ... (1)
6. TDM bytes in frame(x48 bytes)[1 - 30] ... (1)
7. Payload format (V2)
8. OAM connectivity (Disable)
9. Jitter buffer [msec][3 - 300] ... (300)
10. OOS mode (Tx OOS)
11. VLAN tagging (Enable)
12. VLAN ID[1 - 4095] ... (1)
13. VLAN priority[0 - 7] ... (7)
>
Please select item <1 to 13>
F - Forward Bundle ID; D - Delete; ? - Help
ESC-prev.menu; !-main menu; &-exit
Figure 4-21. Bundle Connection Menu when Connection Mode=TDMoIP CE, PSN Type=UDP/IP
