Installation and Operation Manual Appendix C SNMP Management
IPmux-11 Ver. 2.00 SNMP Environment C-3
MIBs Supported by the IPmux-11 SNMP Agent
The interpretation of the relevant MIBs is a function of the SNMP agent of each
managed entity. The general MIBs supported by the IPmux-11 SNMP agent are:
• rfc1213.mib (except the interfaces view which is supported via RFC 2233)
• ianaiftype.mib (defines the ifType)
• rfc2233.mib (IF-MIB)
• rfc2011.mib
• rfc2012.mib
• rfc2013.mib
• rfc1907.mib
• rfc2683.mib
• rfc1215.mib
• rfc1493.mib
• rfc1643.mib
• rfc2239.mib
• rfc2494.mib
• rfc2261.mib
• rfc1695.mib
• rfc2674.mib
• rfc2819.mib
• rfc2495.mib (except Far End objects and RW configuration objects which are
different for each configuration) - replaces RFC 1406; which is now obsolete.
• IPmux RAD private mib.
The IPmux-11 object ID is
iso (1).org(3).dod(6).internet(1).private(4).enterprises(1).rad(164).radGen(6).
systems(1).radSysIPMux(3).IPmux11(106)
Enterprise-specific MIBs supported by RAD equipment, including IPmux-1/1E6,
are available in ASN.1 format from the RAD Technical Support department.
Management Domains under SNMP
In principle, SNMP allows each management station that recognizes the MIBs
supported by a device to perform all the management operations available on that
device. However, this is not desirable in actual practice, it is necessary to provide a
means to delimit management domains.
