Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Configuring IPmux-11 for Operation 4-19
3. When the required Ethernet interface is displayed, configure the following:
Channel state:
Enable (Current Ethernet interface is enabled)
Disable (Current Ethernet interface is disabled)
Auto negotiation:
Enable (Autonegotiation is enabled)
Disable (Autonegotiation is disabled)
Max capability advertised (Maximum capability to be advertised during the
autonegotiation process):
10BaseT Half Duplex
10BaseT Full Duplex
100BaseT Half Duplex
100BaseT Full Duplex
Default type (Rate and duplex mode, if the autonegotiation is disabled):
10BaseT Half Duplex
10BaseT Full Duplex
100BaseT Half Duplex
100BaseT Full Duplex
When autonegotiation protocols do not support each other, this will degrade the
connection to a half-duplex mode. In order to avoid this, autonegotiation should be
disabled and the ports should be configured manually. Half-duplex degradation will
occur also when autonegotiation is enabled at one port and disabled at the
opposite port.
4. Type S to save your changes.
Configuration>Physical layer>ETH
Channel > (Network-Eth1)
1. Channel state (Enable)
2. Auto negotiation (Disable)
3. Max capability advertised > (100baseT Full Duplex)
4. Default type > (100baseT Full Duplex)
>
Please select item <1 to 4>
F – Forward
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-18. ETH Menu
Note
