DIP Switches
ADAPTER,
WIRELESS
ADAPTER
On the back of the printer, you will find a small window where you
can access two DIP switches labeled 1 and 2 (see Figure 2 on
page 42). The functions of the DIP switches are explained in
Table 7.
NOTE: The DIP switches are not marked with “on” or “off” labels.
Instead, the status of the switch is indicated by its position,
up or down. If the interface card has been installed upside
down (i.e., the DIP switches are to the left of the cable
connector), your DIP switch positions will be reversed and
the settings inverted.
Table 7. 10/100Base-T DIP Switch Settings
DIP Switch
Comments
1 2
up up Normal operation. With both DIP switches in the “off” position, the
Ethernet Interface boots up using the settings in flash memory rather
than the default settings.
down up Factory default. With the DIP switches in this configuration, the
Ethernet Interface boots up and all settings stored in flash memory
are erased except the Ethernet address and key value.
up down Default IP. With the DIP switches in this configuration, the Ethernet
Interface boots up with factory default settings. However, the stored
settings in flash memory are intact. Setting DIP switch 2 to “on” does
not clear any settings stored in flash memory; it boots the unit in a
different state with the settings in flash memory temporarily ignored.
down down Reserved. This DIP switch configuration is not for customer use.
