CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®

Revision 7

Front Panel Operation

MN/CDMQX.IOM

5–12

CONFIG: Remote

Æ Ethernet Æ SNMP Æ Communities Æ Write

Write Community: (◄ ► ▲ ▼,ENT)
private

Edit either the SNMP Read or Write Community string by first selecting the
character to be edited using the

arrow keys, then change the character to be

edited by using the dc arrow keys. Only the first 20 characters on the bottom line
are available.

All printable ASCII characters are available with the exception of the backslash ( \
ASCII code 92) and the tilde (~ ASCII code 126). Once the string has been
composed, press

ENTER

. All trailing spaces are removed from the Read or Write

Community string upon entering.

CONFIG: Remote

Æ Ethernet Æ SNMP Æ Traps

Traps: Community Version
IP Addr#1 IP Addr#2 (◄ ►,ENT)

Select Community, Version, IP Addr#1, or IP Addr#2 using the ◄ ► arrow keys,
then press

ENTER

. Selecting Read displays the following submenu:

CONFIG: Remote

Æ Ethernet Æ SNMP Æ Traps Æ Community

Trap Community: (◄ ► ▲ ▼,ENT)
comtech

Edit the Trap Community string by first selecting the character to be edited using the

arrow keys, then change the character to be edited by using the dc arrow keys.

Only the first 20 characters on the bottom line are available.

All printable ASCII characters are available with the exception of the backslash ( \
ASCII code 92) and the tilde (~ ASCII code 126). Once the string has been
composed, press

ENTER

. All trailing spaces are removed from the Community string

upon entering.

CONFIG: Remote

Æ Ethernet Æ SNMP Æ Traps Æ Version

Trap Version: (◄ ►,ENT)
SNMPv1 SNMPv2

Select SNMPv1 or SNMPv2 using the ◄ ► arrow keys, then press

ENTER

CONFIG: Remote

Æ Ethernet Æ SNMP Æ Traps Æ IP Addr#X

Trap IP Addr#X: (◄ ► ▲ ▼,ENT)
000.000.000.000

Where ‘X’ designates the menu selection as IP Addr#1 -or- IP Addr#2: These two
IP Addresses are Trap Destination IP Addresses. Edit the IP Address by first
selecting the digit to be edited using the

arrow keys, then change the value of the

digit to be edited by using the dc arrow keys. Press ENTER when done.

Note: If both Trap IP Address are set to 000.000.000.000, it means Trap is disabled.
