CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Appendix C MN/CDMQX.IOM
C–22
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Request to
Send RTS= 1 byte, value of
0, 1, 2 Command or Query.
Defines how RTS/CTS will operate at the main data interface in the
form x, where:
0=RTS/CTS Loop, No Action
RTS and CTS are looped, so that CTS echoes the state of RTS,
but RTS does not control the ON/OFF state of carrier.
1=Loop, RTS Controls TX O/P
RTS and CTS are looped, so that CTS echoes the state of RTS
and RTS controls the ON/OFF state of carrier (in order words, the
modem will not bring up its TX carrier until RTS is asserted.
2=Ignore RTS, Assert CTS
Example: RTS=0 (RTS/CTS Loop, No Action)
RTS=
RTS?
RTS*
RTS#
RTS^ RTS? RTS=x
(see Description of
Arguments)
Statistics
Sample
Interval SSI= 1 byte,
numerical
Command or Query.
Sets the sample interval for the Statistics Logging Function I n the
form x, where:
x = 0 to 9 in 10-minute increments
Note: Setting this parameter to 0 disables the statistics logging
function.
Example: SSI=3 means 30 minutes
SSI=
SSI?
SSI*
SSI#
SSI^ SSI?
RTC Time TIM= 6 bytes Command or Query.
Sets time, indicated from midnight, in the form hhmmss, where:
hh=hours (00 to 23)
mm=minutes (00 to 59
ss=seconds (00 to 59)
Example: TIM=231259 (23 hours, 12 minutes, 59 seconds)
TIM=
TIM?
TIM*
TIM#
TIM^ TIM? TIM= hhmmss
(see Description of
Arguments)
Test Mode
(Modem or
Tx only) TST= 1 byte, value of
0 through 6 Command or Query.
Test Mode in the form x, where:
0=Normal Mode (No Test)
1=IF Loopback
2=Reserved
3=I/O Loopback
4=RF Loopback
5=TX CW
6=TX Alternating 1,0 Pattern
7=SSB CW
Example: TST=1 (IF Loopback)
TST=
TST?
TST*
TST#
TST$
TST^
TST@ TST? TST=x
(see Description of
Arguments)
