Mocomtech CDM-QX - Manual (Page 133)

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Ethernet Management MN/CDMQX.IOM
6–3
The modem supports both SNMPv1 traps and SNMPv2 notifications. Which style of traps the
modem sends can be configured by the user via the cdmQxSNMPTrapVersion OID.
The following are the MIB2 v1traps/v2 notifications that the modem supports:
MIB2 SNMPv1 trap: Authentication Failure 5
MIB2 SNMPv2 notifications: Authentication Failure 1.3.6.1.6.3.1.1.5.5
The following tables are the Alarms and Faults v1 traps / v2 notifications that the modem supports.
Alarms and Faults SNMPv1 traps:
cdmQxTxTrafficAlarmV2 6247272
cdmQxUnitAlarmV2 6247271
cdmQxRxTrafficAlarmV2 6247273
Alarms and Faults SNMPv2 notifications:
cdmQxUnitAlarm 1.3.6.1.4.1.6247.34.2.0.1
cdmQxTxTrafficAlarm 1.3.6.1.4.1.6247.34.2.0.2
cdmQxRxTrafficAlarm 1.3.6.1.4.1.6247.34.2.0.3
