CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Appendix C MN/CDMQX.IOM
C–11
C.6.2 Receive (Rx) Commands and Queries
Priority System = RFT (Highest Priority), RMD, RCR, RRS, and RDR (Lowest Priority), as indicated by shading. Any changes to a higher
priority can override any of the parameters of lower priority.
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
RX FEC Type RFT= 1 byte, value
of 0 through 6 Command or Query.
RX FEC Type in the form x, where:
0=Reserved
1=Viterbi
2=Viterbi + Reed-Solomon
3=Reserved
4=Reserved
5=TCM + Reed-Solomon
6=Turbo
Example: RFT=1 (Viterbi only)
RFT=
RFT?
RFT*
RFT#
RFT$
RFT^
RFT@ RFT? RFT=x
(see Description of
Arguments)
RX Demod
Type RMD= 1 byte, value
of 0 through 5 Command or Query.
RX Demodulator Type in the form x, where:
0=BPSK
1=QPSK
2=Reserved
3=8-PSK
4=16-QAM (Turbo or Viterbi + Reed-Solomon)
5=Reserved
Depending on FEC type, not all of these selections will be valid.
All other codes are invalid.
Example: RMD=1 (QPSK)
RMD=
RMD?
RMD*
RMD#
RMD$
RMD^
RMD@ RMD? RMD=x
(see Description of
Arguments)
RX FEC
Code Rate RCR= 1 byte, value
of 0 through 7 Command or Query.
Rx FEC Code Rate in the form x, where:
0=Rate 5/16 (Turbo Only)
1=Rate 21/44 (Turbo Only)
2=Rate 1/2
3=Rate 2/3 (8-Psk TCM or 8-QAM only)
4=Rate 3/4
5=Rate 7/8
6= Rate 17/18 (Turbo Only)
7= Reserved
Depending on FEC and demodulation type, not all of these
selections will be valid.
Example: RCR=4 (Rate 3/4)
RCR=
RCR?
RCR*
RCR#
RCR$
RCR^
RCR@ RCR? RCR=x
(see Description of
Arguments)
