Mocomtech CDM-QX - Manual (Page 137)

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Ethernet Management MN/CDMQX.IOM
6–7
6.5.3 User Login
To initiate a Web session with the CDM-Qx/QxL Modem, from the PC type
http://www.xxx.yyy.zzzz (where “www.xxx.yyy.zzz” represents the IP address of the CDM-Qx/QxL
Multi-Channel Satellite Modem) into the Address area of the Web browser:
The Login window will appear, and the user is prompted to type a User Name and Password.
HTTP Login Access Levels are defined as follows:
User Interface
User Login Access Level
Admin User Read/Write User Read Only User
Web
Full Access to
all Web Pages
No Access to Admin or
Encryption Web pages No Access to Admin or Encryption
Web pages
Full Access for all other
Web Pages View Only Access for all other Web
Pages
CDM-Qx/QxL Satellite Modem Web Server Default
Name/Passwords are:
Admin comtech/comtech
Read/Write opcenter/1234
Read Only
monitor/1234
Type the User Name and Password, then click [OK].
Once the valid User Name and Password is accepted, the user will see the CDM-Qx/QxL Multi-
Channel Satellite Modem Web Server Interface “splash” page (right). From this top level menu,
depending on the unit in use the user has access to four or five navigation tabs:
• Home
• Admin (Administration)
• Config (Configuration)
• ODU (Outdoor Unit)*
• Maint (Maintenance).
* CDM-QxL only.
Click any tab to continue.
