CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Front Panel Operation MN/CDMQX.IOM
5–61
UTILITY: Firmware Æ Information Æ Image#1, Image#2
Image#x: Bulk Firmware (▲ ▼)
FW/00107E 05/20/09 2.1.5
For either Image#1 or Image#2: Use the ST arrow keys to browse through each read-only
screen for each component of the firmware image.
Examples:
Image#x: App Firmware (▲ ▼)
FW/00109E 05/20/09 2.1.5
Image#x: Mod FPGA (▲ ▼)
FW/11251G 06/05/08 1.1.8
Press
ENTER
or
CLEAR
to return to the previous menu.
UTILITY: Firmware
Æ Information Æ CPLD
CPLD Info:
FW/11255 Tx=1.2.4 Rx=1.2.4
Firmware versions for both the Modulator and Demodulator modules are shown, as per the above
example. Press
ENTER
or
CLEAR
to return to the previous menu.
5.9.6.3 UTILITY: Firmware
Æ Select
Current Active Image: #1
Next Reboot Image: #1 #2
The top line shows the current active boot image. Using the ◄ ► arrow keys, on the bottom line, the
user may select #1 or #2 as the image that will be active the next time the unit is rebooted. Press
ENTER
when done.
