CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Appendix C MN/CDMQX.IOM
C–20
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Internal
Redundancy
Mode IRM= 5 bytes Command or Query.
Redundancy mode in the form x,abc, where:
For x:
0 = No Redundancy
1=1:1 modem (back-up modules at Slot#3 and Slot#4), or
1:1 Tx (back-up Tx on Slot#4), or
1:1 Rx (back-up Rx on Slot#4)
2=1:2 Tx, or 1:2 Rx (back-up module on Slot#4)
3=1:3 Tx, or 1:3 Rx (back-up module on Slot#4)
4=Reserved
For abc:
000=no redundancy or 1:1 modem or 1:3 Tx or 1:3 Rx.
If a=1, Slot#1 is selected as primary, otherwise it’s not.
If b=1, Slot#2 is selected as primary, otherwise it’s not.
If c=1, Slot#3 is selected as primary, otherwise it’s not.
Note: The settings on a,b, and c fields are only required if Qx is in 1:1
Tx or 1:1 Rx or 1:2 Tx or 1:2 Rx .
Example: IRM =1,000 (1:1 modem)
IRM =1,010 (1:1 Tx or 1:1 Rx with primary at Slot#2)
IRM =
IRM?
IRM*
IRM#
IRM$
IRM^ IRM? IRM = x,abc
(see Description of
Arguments
Initialize
Statistics
Pointer ISP= None Command only.
Resets internal pointer to allow RNS? Queries to start at the
beginning of the statistics log.
ISP=
ISP#
ISP^ N/A N/A
T1 Line
Build-Out LBO= 1 byte, value of
0 though 4 Command or Query.
Valid only for T1 interface in the form x, where:
0=0 to 133 feet
1=133 to 266 feet
2=266 to 399 feet
3=399 to 533 feet
4=533 to 655 feet
Example: LBO=2
LBO=
LBO?
LBO*
LBO#
LBO$
LBO^
LBO@ LBO? LBO=x
(see Description of
Arguments)
Local/Remote
Status LRS= 1 byte, value of
0, 1 Command or Query.
Local/Remote status in the form x, where:
0=Local
1=Serial Remote
3=Ethernet Remote
Example: LRS=1 (Serial Remote)
LRS=
LRS?
LRS*
LRS# LRS? LRS=x
(see Description of
Arguments)
