CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Ethernet Management MN/CDMQX.IOM
6–6
6.5 Web Server (HTTP) Interface
The sections that follow describe the functionality of the CDM-Qx/QxL Multi-Channel
Satellite Modem Web Server (HTTP) Interface. Please refer to Chapter 5. FRONT PANEL
OPERATION, and the Remote Commands Specifications tables found in Appendix C.
REMOTE CONTROL for detailed descriptions of the configuration parameters featured on
the individual Web pages shown in this chapter.
6.5.1 Web Server Introduction
The embedded Web Server application provides the user with an easy to use interface to
configure and monitor all aspects of the CDM-Qx/QxL. These Web pages have been designed for
optimal performance when using Microsoft’s Internet Explorer Version 5.5 or higher (the
examples shown use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of
the CDM-Qx/QxL from the Web Server Interface. By
rolling the cursor over the navigation tabs located at the top
of each page (right), the user can select from the available
nested hyperlinks.
6.5.2 Web Server Menu Tree
The menu tree illustrates the options available through this interface:
*This navigation tab and its supported hyperlinks are visible/accessible only with a properly-
configured CDM-QxL (L-Band) unit.
IMPORTANT
Prior to starting a new Web session, be sure to clear the browser cache of any
pages accessed during earlier Web sessions.
Home Admin Config ODU* Main
Home Access
Quick
View
BUC
Unit
Info
Contact Remote
Unit
Status
LNB
Support
