CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Appendix C MN/CDMQX.IOM
C–32
C.6.5 Bulk Commands and Queries
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Global
Configuration MGC= 138 bytes, with
numerical entries,
fixed values and
delimiters
Command or Query.
Global Configuration of CDM-QX on a module Slot basis if not grouped as a modem or on
a modem basis if grouped. If the module is a Tx and ungrouped as modem, the Rx field
will be filled with ‘x’, and vice-versa.The format is:
abcdddd.ddddefghhhhh.hhhijkk.klmnoppp.ppqrstuvvvvvvvAAAA.AAAABCDEEEEE.EEEF
GHIIIJJ.JKLMNOPPPPPPPQRSSSSTUUUUUUUUUUUUVWXYYYZZZ.ZZZaaabbbbbbb
b where:
MGC=
MGC?
MGC*
MGC#
MGC$
MGC^ MGC?
MGC?n MGC=abcdddd.ddddefghhhhh.hhhij
kk.klmnoppp.ppqrstuvvvvvvvAAAA.
AAAABCDEEEEE.EEEFGHIIIJJ.JK
LMNOPPPPPPPQRSSSSTUUUUU
UUUUUUUVWXYYYZZZ.ZZZaaab
bbbbbbb
Where n=0 to 9
Returns the MGC portion of 1 of 10
stored configurations
(see Description of Arguments)
a=Unit Interface Type
b=T1 Line Build-out
c=Unit framing mode
dddd.dddd=Tx Frequency
e=Tx FEC Type
f=Tx Modulation Type
g=Tx FEC Rate
hhhhh.hhh=Tx Data Rate
i=Tx Spectrum Inversion
j=Tx Scrambler State
kk.k=Tx Power Level
l=Tx Clock Source
m=Tx Data Invert
n=Tx Carrier State
o=AUPC Enable
ppp.pp=AUPC Parameter Setup
q=Warm-up Delay
r=Tx Common Output state
s=Tx Reed-Solomon (n, k) value
t=Tx roll-off (alpha) factor
u=Tx Data Clock Invert
vvvvvvv=Expansion Bytes
AAAA.AAAA=RX Frequency
B=RX FEC Type
C=RX Modulation Type
D=RX FEC Rate
EEEEE.EEE=RX Data Rate
F=RX Spectrum Inversion
G=RX Descrambler State
H=RX Data Invert
III=RX Sweep Width
JJ.J=Eb/No Alarm Point
K=RX Buffer Clock Source
L=RX Reed-Solomon (n, k) values
M= RX Buffer Size
N=RX Data Clock Invert
O=Rx roll-off (alpha) factor
PPPPPPP=Expansion Bytes
Q=External Reference Bytes
R=EDMAC Framing Mode
SSSS=EDMAC Slave Address
T=Unit Test Mode (Read only)
UUUUUUUUUUUU=Unit Alarm Mask
V=RTS/CTS Control
W=Statistics Sampling Interval
X=CnC Mode
YYY=CnC Frequency Offset
ZZZ.ZZZ=CnC Min/Max Search Delay
aaa=CnC Re-Acquisition time
bbbbbbbb=Epansion Bytes
Fill unused expansion bytes with ‘x’ same as ITF
same as LBO
same as FRM
same as TFQ
same as TFT
same as TMD
same as TCR
same as TDR
same as TSI
same as TSC
same as TPL
same as TCK
same as TDI
same as TXO
same as AUP
same as APP
same as WUD
same as TXC
same as TRS
same as TXA
same as TCI
same as RFQ
same as RFT
same as RMD
same as RCR
same as RDR
same as RSI
same as RDS
same as RDI
same as RSW
same as EBA
same as BCS
same as RRS
same as RBS
same as RCI
same as RXA
same as ERF
same as EFM
same as ESA
same as TST
same as MSK
same as RTS
same as SSI
same as CNM
same as CCF
same as CSD
same as CRA
