CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier® Revision 7
Appendix B MN/CDMQX.IOM
B–4
B.2.2.2 View Installed Module (Mod/Demod, Turbo) FAST Features
Select MAIN MENU: Utility Æ Fast Æ Slot# using the ◄ ► arrow keys, then press
ENTER
.
FAST - Slot#2: Demod Turbo
(▲ ▼,ENT)
Depending on the installed module, select Mod (Demod) or Turbo using the ◄ ► arrow keys,
then press
ENTER
.
1. If Mod (Demod) is selected (a Demod module is shown in this example):
FAST: Config View
Board S/N: 323456789 (Dem#2)
Select View using the ◄ ► arrow keys, then press
ENTER
.
View Options: 02 (▲ ▼,ENT)
1:2 Redun - Installed
Use the ▲ ▼ arrow keys to display which FAST options are either Installed or Not
Installed for mod/demod operation. Any feature identified as Not Installed may be
purchased from Comtech EF Data. Press
ENTER
when done.
Note the following (typical for either modulator or demodulator modules):
View Option No.
(Top Line)
FAST Option Name
(Bottom Line)
Description
01 TPC Codec
02 Future H/W
03 5Mbps Card
04 10Mbps Card
05 20Mbps Card
06 8-PSK
07 16-QAM
08 Future H/W
09 Future S/W
2. If Turbo is selected:
View Options: 03 (▲ ▼,ENT)
5M Turbo - Installed
Use the ▲ ▼ arrow keys to display which FAST options are either Installed or Not
Installed for TPC operation. Any feature identified as Not Installed may be
purchased from Comtech EF Data. Press
ENTER
when done.
Note the following (typical for either modulator or demodulator modules):
View Option No.
(Top Line)
FAST Option Name
(Bottom Line)
Description
01 Future S/W
02 Future S/W
03 5M Turbo
04 10M Turbo
05 20M Turbo
06 Future H/W
07 Future S/W
