F. Chapter 5

Registers

After a power-on reset (POR), all fields of

DCUCR

, including implementation-

dependent fields, are set to 0. After a

WDR

XIR

, or

SIR

reset, all fields of

DCUCR

including implementation-dependent fields, are set to 0.

The Data Cache Unit Control Register is illustrated in

FIGURE 5-2

and described in

TABLE 5-3

. In the table, bits are grouped by function rather than by strict bit sequence.

FIGURE 5-2

DCU Control Register Access Data Format (ASI 45

)

TABLE 5-3

DCUCR Description

Bits

Field

Type

Use — Description

49:48

Not implemented in SPARC64 V (impl. dep. #232). It reads as 0 and writes to
it are ignored.

47:42

impl. dep.

Not used. It reads as 0 and writes to it are ignored.

WEAK_SPCA

Used for disabling speculative memory access (impl. dep. #240). When

DCUCR.WEAK_SPCA

, the branch history table is cleared and no longer

issues aggressive instruction prefetch.
During

DCUCR.WEAK_SPCA

, aggressive instruction prefetching is

disabled and any load and store instructions are considered presync
instructions that are executed when all previous instructions are committed.
Because all CTI are considered as not taken, instructions residing beyond 1
Kbyte of a CTI may be fetched and executed.
On entering aggressive instruction Prefetch disable mode, supervisor
software should issue

membar #Sync

, to make sure all in-flight instructions

in the pipeline are discarded.
During

DCUCR.WEAK_SPCA

= 1, an L2 cache flush by writing 1 to

ASI_L2_CTRL.U2_FLUSH

remains pending internally until

DCUCR.WEAK_SPCA

is set to 0. To wait for completion of the cache flush, a

member #Sync

must be issued after

DCUCR.WEAK_SPCA

is set to 0.

Executing a

membar #Sync

while the

DCUCR.WEAK_SPCA

= 1 after writing 1

ASI_L2_CTRL.U2_FLUSH

does not wait for the cache flush to complete.

40:33

<7:0>
