Release 1.0, 1 July 2002 F. Chapter F Memory Management Unit 89
8K_POINTER = TSB_Extension[63:14+N] 0 (VA[21+N:13]
⊕
TSB_Hash)
0000
64K_POINTER = TSB_Extension[63:14+N] 1 (VA[24+N:16]
⊕
TSB_Hash) 0000
Value of TSB_Hash for both a shared TSB and a split TSB
When 0 <= N <= 4,
TSB_Hash = context_register[N+8:0]
Otherwise, when 5 <= N <= 15,
TSB_Hash [ 12:0 ] = context_register[ 12:0 ]
TSB_Hash [ N+8:13 ] = 0 ( N-4 bits zero )
F.5 Faults and Traps
IMPL. DEP. #230 : The cause of a data_access_exception trap is implementation
dependent in JPS1, but there are several mandatory causes of data_access_exception
trap.
SPARC64 V signals a data_access_exception for the causes, as defined in F.5 in
Commonality . However, caution is needed to deal with an invalid ASI. See
Section F.10.9 for details.
IMPL. DEP. #237 : Whether the fault status and/or address ( DSFSR / DSFAR ) are
captured when mem_address_not_aligned is generated during a JMPL or RETURN
instruction is implementation dependent.
On SPARC64 V, the fault status and address ( DSFSR / DSFAR ) are not captured
when a mem_address_not_aligned exception is generated during a JMPL or RETURN
instruction.
Additional information: On SPARC64 V, the two precise traps—
instruction_access_error and data_access_error —are recorded by the MMU in addition
to those in TABLE F-2 of Commonality. A modification (the two traps are added) of
that table is shown below.
TABLE F-2 MMU Trap Types, Causes, and Stored State Register Update Policy
Registers Updated
(Stored State in MMU)
Ref #Trap Name Trap Cause I-SFSR
I-MMU
Tag
Access
D-SFSR,
SFAR
D-MMU
Tag
Access
Trap Type
1. fast_instruction_access_MMU_miss I-TLB miss X2 X 64
16
–67
16
