Release 1.0, 1 July 2002 F. Chapter R UPA Programmer’s Model 217
29:23 PCON Processor Configuration. Separated into PCON <6:4> and PCON <3:0>.
PCON <6:4> ( UPA_CONFIG <29:27>) represents the size of class 1 request queue in the
System Controller (SC).
000
2
: 1
001
2
– 010
2
: 1, but should not be specified for the extension
011
2
: 4
100
2
– 110
2
: 4, but should not be specified for the extension
111
2
: 8
PCON <3:0> ( UPA_CONFIG <26:23> represents the size of class 0 request queue in the
System Controller (SC).
0000
2
: 1
0001
2
– 0010
2
: 1, but should not be specified for the extension
0011
2
: 4
0100
2
– 1110
2
: 4, but should not be specified for the extension
1111
2
: 16
22 UPC_CAP2 This field is connected to the UPA’ Port ID register bit 35, SREQ_S field
21:17 MID Module (Processor) ID register. Identifies the unique processor ID. This value is loaded
from the UPA_MasterID<4:0> pins.
16:0 UPC_CAP This field is a composite of the following fields in the UPA’ Port ID register.
16:15 PINT_RDQ
14:9 PREQ_DQ
8:5 PREQ_RQ
4:0 UPA_CAP
TABLE R-3 UPA Config Register Description (Continued)
Bits Field Description
