184 SPARC JPS1 Implementation Supplement: Fujitsu SPARC64 V • Release 1.0, 1 July 2002
Error Detect
Condition Always Error is always checked.
AUG always Error is checked when ( ASI_ERROR_CONTROL.UGE_HANDLER = 0) &&
( ASI_ERROR_CONTROL.WEAK_ED = 0).
LDXA Error is checked when the register is read by LDXA instruction.
LDXA #I Error is checked when the register is read by LDXA instruction.
Also, the register is used for the calculation of IMMU_TSB_8KB_PTR and
IMMU_TSB_64KB_PTR . When the register has a UE and the register is used
for the calculation of ASI_IMMU_TSB_PTR registers, the UE is propagated to
the ASI_IMMU_TSB_PTR registers. Upon execution of the LDXA instruction
to read ASI_IMMU_TSB_PTR with the propagated UE , the IUG_TSBP error is
detected.
LDXA #D Error is checked when the register is read by LDXA instruction.
Also, the register is used for the calculation of DMMU_TSB_8KB_PTR ,
DMMU_TSB_64KB_PTR , and DMMU_TSB_DIRECT_PTR . When the register has
a UE and the register is used for the calculation of ASI_DMMU_TSB_PTR
registers, the UE is propagated to the ASI_DMMU_TSB_PTR registers. Upon
execution of the LDXA instruction to read ASI_DMMU_TSB_PTR with the
propagated UE , the IUG_TSBP error is detected.
ITLB write Error is checked at the ITLB update timing after completion of the STXA
instruction to write or demap an ITLB entry.
DTLB write Error is checked at the DTLB update timing after the completion of the STXA
instruction to write or demap a DTLB entry.
Use for TLB Error is checked when the register is used for a TLB reference.
Enabled Error is checked when the facility is enabled.
intr_receive Error is checked when the UPA interrupt packet is received. When an
uncorrectable error is detected in the received interrupt packet, the vector
interrupt trap is caused but
ASI_INTR_RECEIVE.BUSY = 0 is set. In this
case, a new interrupt packet can be received after software writes
ASI_INTR_RECEIVE.BUSY = 0.
BV interface Uncorrected error in the Barrier Variable transfer interface between the
processor and the memory system is checked during the AUG_always
period.
(2 of 3)
Column Term Meaning
