170 SPARC JPS1 Implementation Supplement: Fujitsu SPARC64 V • Release 1.0, 1 July 2002
Errors in registers other than those listed above and any errors in the TLB entry
remain.
b. Update of ASI_UGESR , as shown in TABLE P-13 .
c. Update of ASI_ERROR_CONTROL
Upon a single- ADE trap, ASI_ERROR_CONTROL.UGE_HANDLER is set to 1.
During the period after the single- ADE trap occurs and before a RETRY or DONE
instruction is executed, UGE_HANDLER = 1 tells hardware that the urgent error
handler is running.
Upon a multiple async_data_error trap, ASI_ERROR_CONTROL.WEAK_ED is set
to 1 and the CPU starts running in the weak error detection state.
4. Set ASI_ERROR_CONTROL.UGE_HANDLER to 0.
Upon completion of a RETRY or DONE instruction,
ASI_ERROR_CONTROL.UGE_HANDLER is set to 0.
P.4.3 Instruction End-Method at ADE Trap
In SPARC64 V, upon occurrence of the ADE trap, the trapped instruction referenced
by TPC ends by using one of the following instruction end-methods:
■
Precise
■ Retryable but not precise (not included in JPS1)
■ Not retryable (not included in JPS1)
Upon a single-ADE trap, the trapped instruction end-method is indicated in
ASI_UGESR.INSTEND .
TABLE P-13 ASI_UGESR Update for Single and Multiple- ADE Exceptions
Bit Field Update upon a Single-ADE Trap Update upon a Multiple-ADE Traps
63:6 Error indication All bits in this field are updated.
All I_UGE s and A_UGE s detected at the
trap are indicated simultaneously.
Unchanged.
5:4 INSTEND The instruction end-method of the
instruction referenced by
TPC is set.
Unchanged.
2 MUGE_DAE [ Set to 0. If the multiple- ADE trap was caused by a
DAE , MUGE_DAE is set to 1.
Otherwise, MUGE_DAE is unchanged.
1 MUGE_IAE Set to 0. If the multiple- ADE trap was caused by
an IAE , MUGE_IAE is set to 1.
Otherwise, MUGE_IAE is unchanged.
0 MUGE_IUGE Set to 0. If the multiple- ADE trap was caused by
an I_UGE , MUGE_IUGE is set to 1.
Otherwise, MUGE_IUGE is unchanged.
