164 SPARC JPS1 Implementation Supplement: Fujitsu SPARC64 V • Release 1.0, 1 July 2002
P.3.2 Fatal Error Types
■ FE_UPA_ADDR_UNCORRECTED_ERROR — An uncorrected error in the
address received from UPA
■
FE_U2TAG_UNCORRECTED_ERROR — An uncorrected error detected in the U2
cache tag
■ FE_OTHER — A fatal error other than those listed above
P.3.3 Types of error_state Transition Errors
■ EE_TRAP_IN_MAXTL — A trap occurred while TL = MAXTL .
■
EE_SIR_IN_MAXTL — An SIR occurred while TL = MAXTL .
■ EE_SECOND_WATCH_DOG_TIMEOUT — A second watchdog timeout was
detected after an
async_data_error exception with watchdog timeout indication
(first watchdog timeout) was generated.
■ EE_WATCH_DOG_TIMEOUT_IN_MAXTL — A watchdog timeout occurred
while
TL = MAXTL .
■
EE_OPSR —An uncorrectable error occurred in OPSR (Operation Status Register);
valid CPU operation after such an error cannot be guaranteed. OPSR is the
hardware mode-setting register. OSPR is not visible to software and is set by a
JTAG command.
■
EE_TRAP_ADDR_UNCORRECTED_ERROR — When hardware calculated the
trap address to cause a trap, the valid address could not be obtained because of a
UE in ASI_TBA , a UE in %tt , or a UE in the address calculator.
■ Other error_state transition errors:
■
Current SPARC64 V implementation
When hardware detects an
error_state transition error other than those
described above, it causes a watchdog reset without setting any EE_ xxxx bits in
ASI_STCHG_ERROR_INFO .
9 EE_SIR_IN_MAXTL R Upon detection of the corresponding error, set to 1.
8 EE_TRAP_IN_MAXTL R Upon detection of the corresponding error, set to 1.
7:3 Reserved R Always 0.
2 FE_OTHER R Upon detection of the corresponding error, set to 1.
1 FE_U2TAG_UNCORRECTED_ERROR R Upon detection of the corresponding error, set to 1.
0 FE_UPA_ADDR_UNCORRECTED_ERROR RW Upon detection of the corresponding error, set to 1.
Writing 1 to this bit sets all fields in this register to 0.
TABLE P-10 Format of ASI_STCHG_ERROR_INFO Bit Description (Continued)
Bit Name RW Description
