Administrator Procedures

AXXESS

ADMINISTRATOR’S GUIDE – January 2004

Trunk Programming

To Program an Individual Trunk: Press

or the INDIVIDUAL TRUNK menu but-

ton. Then program trunk options as follows:

a. The display shows ENTER TRUNK EXTENSION. Enter the extension number of

the trunk to be programmed using one of the methods described on

page 25

b. The display shows INDIVIDUAL TRUNK OPTION. Enter one of the following

options. To view the last two options on a display phone, press the arrow (<< or
>>) menu button at the bottom of the display.

Answer Supervision: To program the answer supervision for the trunk, press

the ANS SUPERVISION menu button. When the display shows ANS SUPERVI-
SION OPTION, press

or the POLARITY REVERSE menu button for the

polarity-reversal supervision type. Or, press

or the VALID CALL menu button

for Valid Call timer supervision. Or, press

or the VALID + POLARITY menu

button for Valid Call timer with Polarity Reversal supervision. Then press

ACCEPT to continue.

Caller ID: To enable or disable Caller ID, press

or the CALLER ID menu but-

ton. When the display shows SET CALLER ID, press

or ON to enable the fea-

ture, or press

or OFF to disable it. Then press

or ACCEPT to continue.

Hybrid Balance: To set the hybrid balance of the trunk to normal or short, press
or the HYBRID BALANCE menu button. When the display shows HYBRID
BALANCE OPTION, press

or the NORMAL menu button, or press

or the

SHORT menu button. Then press

or ACCEPT to continue.

DTMF/Dial-Pulse Signaling: To set the trunk for DTMF or dial-pulse signaling,
press

or the SIGNALING menu button. When the display shows ENTER SIG-

NALING OPTION, press

or the DTMF menu button, or press

or the

PULSE menu button. Then press

or ACCEPT to continue.

Trunk Group Number: To assign the trunk to a trunk group, press

or the

TRUNK GROUP menu button. When the display shows ENTER TRUNK GRP
EXTENSION, enter the desired trunk group number using one of the methods
described on

page 25

Busy Trunk: To temporarily remove the trunk from service, press

or the BUSY

TRUNK menu button. When the display shows MARK TRUNK BUSY, press
or the ON menu button, or press

or the OFF menu button. Then press

ACCEPT to continue.

c. To exit, press

or ACCEPT to move backward through the prompts until you

reach the ENTER DATABASE OPTION prompt.

To Program A Trunk Group: Press

or the TRUNK GROUP menu button. Then

program the trunk group, as follows:

a. The display shows ENTER TRUNK GRP EXTENSION. Enter the extension num-

ber of the trunk group to be programmed using one of the methods described on

page 25

b. The display shows ENTER TRUNK GROUP OPTION. Select one of the following

options. To view the last three options on a display phone, press the arrow (<< or
>>) menu button at the bottom of the display.
