MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 21
Pic Wire&Cable D5102QX Hi Temp Quadraxial A/R EA
Pic Wire&Cable D771553 MIL-STD 1553 Data Bus A/R EA
ECS
ECS 4122021
312402 ARINC 453 cable (2 shields)
ARINC 453 cable (3 shields) A/R
A/R EA
EA
Emteq D70-022402T-01 ARINC 453 cable A/R EA
M17/176-00002
M83536/6-022M
M12883/44-01 Military Specification
Relay, 4PDT
(Note 1)
Relay, Socket (Note 1)
A/R
A/R
A/R EA
EA
EA
Note 1: Recommended in EFS 40/50 Installation Manual.
1.9.2 GPS Anten na & Cable
The GPS Antenna & cable can be ordered from their manufacturers using the following part numbers:
Vendor Name
Vendor P/N Description QTY UM Honeywell P/N
Bendix/King 071-01553-0200 KA 92 GPS Antenna (26dB) 1 EA 300-1147-001
Comant CI 405-2 KA 92 GPS Antenna (26dB) 1 EA 300-1147-001
Bendix/King 050-03318-0000 Antenna Installation Kit OPT EA 405-0432-001
Sensor Systems S67-1575-38 S67 GPS Antenna (29dB) 1 EA
Sensor Systems S67-1575-52 S67 GPS Antenna (26dB) 1 EA
Sensor Systems S67-1575-133 S67 GPS Antenna (33dB) 1 EA
Thermax M17/128-RG400 Coax Cable, RG400/U A/R EA
Coax Cable, RG-142B/U A/R EA
PIC S14293 Coax Cable A/R EA
PIC S44191 Coax Cable A/R EA
ECS 311901 Coax Cable A/R EA
ECS 311601 Coax Cable A/R EA
ECS 311201 Coax Cable A/R EA
Amp 225554-6 TNC Angle Plug, Male 1 EA 440-1239-001
Amphenol 79075 TNC Angle Plug, Male 1 EA 440-1239-001
NOTE: If a satellite communication system is installed in the aircraft, or the GPS cable run is in the vicinity of a
VHF transceiver and/or cable, DO NOT USE R/G 142 or R/G 400 cable.
1.9.3 Circuit Brea ker
The Circuit Breaker needs to be a 3 Amp delayed action circuit breaker.
Vendor Name
Vendor P/N Description QTY UM
Klixon (T.I.) 7277-2-3 3 Amp Circuit Breaker,
EGPWS power +28 1 EA
Klixon (T.I.) 7277-2-1 1 Amp Circuit Breaker, lamp
power +28 1 EA
