MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 240
Table 5.3.6.1-255 Honeywell SPZ8000 older style MK VIII Only
Display Configuration Group 255
Function Value Reference section
Display Type Honeywell (5x6) SPZ8000 older style; does not blank every fourth
weather radar display line.
This interface supports SG-810 and SG-811 SPZ8000 systems only.
Sweep Type Honeywell
Category 7, Options Select Group #1
TA&D Alternate Pop Up: False TA&D Alternate Pop Up: True
Auto Pop Up
Pop Up On Caution or Warning Never Pop Up
5.3.7
Category 7, Options Select Group #1
Peaks Enable: False Peaks Enable: True
Peaks Mode
(Elevations via overlay)
Peaks Off Peaks On
5.3.7
Manual select Selection is controlled by display
Manual deselect Deselection is controlled by display
Auto Range Yes (10 NM)
Moving Marker Yes (Honeywell type)
Overlay Page Yes for Peaks Elevations only (located on lower right side)
Display bus type Honeywell picture bus
DISPLAY BUS #1
453TX_1 CONNECT TO:
A = J1-58
B = J1-59 Terrain Display data to switching relay/Symbol Generator #1 4.2.13.2
7.2
DISPLAY BUS #2
453TX_2 CONNECT TO:
A = J1-56
B = J1-57 Terrain Display data to switching relay/Symbol Generator #2
Note: Range setting always follows Display Bus #1 4.2.13.2
7.2
Display Input Control Group 255
CHANNEL
429_422RX_1 CONNECT TO: SCI Bus 1
Format: RS-422 (12K baud) Fault Designation: DISPLAY BUS 1
Bus Type: Basic
A = J2-36
B = J2-37 Data
Range (Mode/Range Word) Reference
6.5.1.1 Label
80 Sig. Bits
4 discrete Range
2000NM Signal Type
Basic Resolution
N/A Rate (ms)
100
Output 429 Bus Group 0
Channel Pins Comments
429TX_1 (Low Speed) A = J2-43
B = J2-42 Transmits (Section 7) Label sets: 7.1.1.x, 7.1.2.x, 7.1.3.x, and 7.1.4.x
Integration Notes:
1. The EGPWS ARINC 429 Output Bus must be connected to the SPZ8000 display.
