MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 238
Table 5.3.6.1-253 Collins FDS 255/2000 with selection controlled by the display MK VIII Only
Display Configuration Group 253
Function Value Reference section
Display Type Collins FDS 255/2000
Sweep Type Fan
Category 7, Options Select Group #1
TA&D Alternate Pop Up: False TA&D Alternate Pop Up: True
Auto Pop Up
Category 7 does not affect pop up logic. The display controls pop up,
therefore enable/disable of pop up is done via the display.
5.3.7
Category 7, Options Select Group #1
Peaks Enable: False Peaks Enable: True
Peaks Mode
Peaks Off Peaks On
5.3.7
Manual select Selection controlled by display
Manual deselect Deselection controlled by display
Auto Range No (see Integration Notes)
Moving Marker No
Overlay Page Yes for Peaks Elevations only (located on lower left of the display)
Display bus type Standard
DISPLAY BUS #1
453TX_1 CONNECT TO:
A = J1-58
B = J1-59 Terrain Display data to switching relay/Symbol Generator #1 4.2.13.2
7.2
DISPLAY BUS #2
453TX_2 CONNECT TO:
A = J1-56
B = J1-57 Terrain Display data to switching relay/Symbol Generator #2 4.2.13.2
7.2
Display Input Control Group 253
CHANNEL
429_422RX_1 CONNECT TO: WX-IND 429 Bus 1 out
Format: ARINC 429 (Low Speed) Fault Designation: DISPLAY BUS 1
Bus Type: Basic
A = J2-37
B = J2-36 Data
Range Reference
6.2.20 Label
273 Sig. Bits
N/A Range
5-320NM Signal Type
Basic Resolution
N/A Rate (ms)
100
CHANNEL
429RX_3 CONNECT TO: WX-IND 429 Bus 2 out
Format: ARINC 429 (Low Speed) Fault Designation: DISPLAY BUS 2
Bus Type: Basic
A = J2-41
B = J2-40 Data
Range Reference
6.2.20 Label
273 Sig. Bits
N/A Range
5-320NM Signal Type
Basic Resolution
N/A Rate (ms)
100
Output 429 Bus Group 0
Channel Pins Comments
429TX_1 (Low Speed) A = J2-43
B = J2-42 Transmits (Section 7) Label sets: 7.1.1.x, 7.1.2.x, 7.1.3.x, and 7.1.4.x
Integration Notes:
1. The EGPWS ARINC 429 Output Bus must be connected to the display.
2. When there is a Terrain Alert and the FDS 255/2000 is not currently displaying Terrain it will set its range to 10 NM
and Pop Up to Terrain mode. The range does not change if Terrain mode is already selected when there is a Terrain
Alert.
3. When interfacing to a single display controller configuration the bus must be connected to both EGPWS input
channels. This prevents the EGPWS from reporting an external bus fault on the second channel.
