Signal Name –MK-VI GPWS (965-0686-001, -020)
Signal Type
Same
Conn/Pin
Signal Type
< IN Out >
Signal Name -MK-VI/MK VIII EGPWS (Enhanced)
J2-27
< 232 IN (A)
Spare RS-232 Input (Tx)
Spare RS-422 Input (A leg)
J2-28
< GND
GPS/Spare RS-232 Common
J2-29
< 232 IN (A)
GPS RS-232 Input (Rcv)
Spare RS-422 Input (A leg)
J2-30
J2-31
< GDisc
Steep Approach #2 (GND)
J2-32
Clock >
Configuration Module Serial Clock
J2-33
Data >
Configuration Module Serial Input
J2-34
< AC Analog (H)
26 VAC Reference #2 (H)
J2-35
< AC Analog (L)
26 VAC Reference #2 (L)
J2-36
< 429 input (B)
Display Range #1 ARINC 429 Input (B leg)
SCI Display Range #1 RS-422 Input (A leg)
IOC #1 ARINC 429 Input (B leg)
J2-37
< 429 input (A)
Display Range #1 ARINC 429 Input (A leg)
SCI Display Range #1 RS-422 Input (B leg)
IOC #1 ARINC 429 Input (A leg)
J2-38
< 429 input (B)
Air Data ARINC 429 Input (B leg)
IOC #1 (Nav) ARINC 429 Input (B leg)
J2-39
< 429 input (A)
Air Data ARINC 429 Input (A leg)
IOC #1 (Nav) ARINC 429 Input (A leg)
J2-40
< 429 input (B)
Display Range #2 ARINC 429 Input (B leg)
IOC #2 ARINC 429 Input (B leg)
J2-41
< 429 input (A)
Display Range #2 ARINC 429 Input (A leg)
IOC #2 ARINC 429 Input (A leg)
J2-42
429 Output (B) >
EGPWS ARINC 429 Output #1 (B leg)
J2-43
429 Output (A) >
EGPWS ARINC 429 Output #1 (A leg)
J2-44
< 232 input (B)
Spare RS-422 Input (B leg)
J2-45
< 232 input (A)
GPS RS-232 Input (Tx)
Spare RS-422 Input (A leg)
J2-46
< 232 input (B)
Spare RS-422 Input (B leg)
J2-47
J2-48
J2-49
< GDisc
Configuration Module Serial Select
J2-50
< Data
Configuration Module Serial Output
