MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896
SCALE: NONE
SIZE: A
DWG NO: 060-4314-150
REV:
SHEET
245
Table 5.3.8-1: Radio Altitude Input Select Type 1 (ALT 55)
SIGNAL
CONNECTION
REFERENCE
SUMMARY DATA
Radio Altimeter #1
(+) = J1-64
(-) = J1-45
6.1.2
4.2.3.1
Format: Alt 55 with Validity Flag
Input Type: Basic
Fault Designation: RADIO ALTIMETER FAULT
Validity: Radio Altitude Valid Discrete #1 (+28V)
PIN FUNCTION
CONNECTION
PIN TYPE
CHANNEL DESIGNATION
REFERENCE
Polarity/Configuration
References
Radio Altitude Validity
Discrete #1 (+28V)
J1-29
Input
28V_DISC_07
>+17V = Valid
<+4.4V = Invalid
6.6.1
4.2.7
DH Discrete (Gnd)
J1-33
Input
GND_DISC_11
Gnd = Below DH
6.6.14
4.2.7
Table 5.3.8-2: Radio Altitude Input Select Type 2 (ARINC 429)
CHANNEL
429RX_5
CONNECT TO: Left LRRA
Format: ARINC 429 (Low Speed)
Fault Designation: RADIO ALTIMETER BUS
Bus Type: Basic
A = J2-21
B = J2-4
Data
Radio Altitude
Reference
6.2.29
Label
164
Sig. Bits
16
Range
±8192 FT
Signal Type
Basic
Resolution
0.125
Rate (ms)
25-50
PIN FUNCTION
CONNECTION
PIN TYPE
CHANNEL DESIGNATION
REFERENCE
Polarity/Configuration
References
DH Discrete (Gnd)
J1-33
Input
GND_DISC_11
Gnd = Below DH
6.6.14
4.2.7
Table 5.3.8-3: Radio Altitude Input Select Type 3 (RT-200/300)
SIGNAL
CONNECTION
REFERENCE
SUMMARY DATA
Radio Altimeter #1
(+) = J1-64
(-) = J1-45
6.1.11
4.2.3.1
Format: DC with Validity Flag (RT-200/300 Precision Output)
Input Type: Basic
Fault Designation: RADIO ALTIMETER FAULT
Validity: Radio Altitude Valid Discrete #1 (+28V)
PIN FUNCTION
CONNECTION
PIN TYPE
CHANNEL DESIGNATION
REFERENCE
Polarity/Configuration
References
Radio Altitude Validity
Discrete #1 (+28V)
J1-29
Input
28V_DISC_07
>+17V = Valid
<+4.4V = Invalid
6.6.1
4.2.7
DH Discrete (Gnd)
J1-33
Input
GND_DISC_11
Gnd = Below DH
6.6.14
4.2.7
Table 5.3.8-4: Radio Altitude Input Select Type 4 (KRA 405)
SIGNAL
CONNECTION
REFERENCE
SUMMARY DATA
Radio Altimeter #1
(+) = J1-64
(-) = J1-45
6.1.2
4.2.3.1
Format: Alt 55 with Validity Flag (KRA-405 Auxiliary Output #1)
Input Type: Basic
Fault Designation: RADIO ALTIMETER FAULT
Validity: Radio Altitude Valid Discrete #1 (+28V)
PIN FUNCTION
CONNECTION
PIN TYPE
CHANNEL DESIGNATION
REFERENCE
Polarity/Configuration
References
Radio Altitude Validity
Discrete #1 (+28V)
J1-29
Input
28V_DISC_07
>+17V = Valid
<+4.4V = Invalid
6.6.1
4.2.7
DH Discrete (Gnd)
J1-33
Input
GND_DISC_11
Gnd = Below DH
6.6.14
4.2.7
