MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 306
7.1.1.3 Mode 6 Callouts Discrete #1 (272)
Data: Discrete
Label: 272 Octal
Significant Bits: (see table below)
Sign Bit: N/A
Transmit Interval: 100 msec ± 10%
BIT NO WARNING MESSAGE (1 = voice on)
11 MINIMUMS
* 12 DECISION HEIGHT
* 13 APPROACHING MINIMUMS
* 14 APPROACHING DECISION HEIGHT
* 15 ZERO (Not supported)
16 TEN
17 TWENTY
18 THIRTY
19 FORTY
20 FIFTY
* 21 SIXTY
* 22 EIGHTY
23 ONE HUNDRED
24 TWO HUNDRED
25 THREE HUNDRED
* 26 MINIMUM
* 27 PLUS HUNDRED
* 28 DECIDE
* 29 FIFTY ABOVE
NOTE (*): Bits 12 - 15, 21, 22 and 26 - 29 will be set to zero, Not supported.
7.1.1.4 Mode 6 Callouts Discrete #2 (273)
Data: Discrete
Label: 273 Octal
Significant Bits: (see table below)
Sign Bit: N/A
Transmit Interval: 100 msec ± 10%
BIT NO DEFINITION (1 = voice on)
11 FOUR HUNDRED
12 FIVE HUNDRED (NORMAL, SMART or ABOVE FIELD)
13 ONE THOUSAND
* 14 700 HZ TONE
* 15 960 HZ TONE
* 16 1400 HZ TONE
* 17 2800 HZ TONE
18 BANK ANGLE (pause) BANK ANGLE
* 19 THIRTY FIVE
* 20 TWENTY FIVE HUNDRED
* 21 RADIO ALTIMETER
* 22 FIVE
23 FIVE HUNDRED ABOVE (ABOVE FIELD)
* 24 (SPARE)
* 25 (SPARE)
* 26 (SPARE)
* 27 FLAPS (pause) FLAPS
* 28 AUTOPILOT
* 29 SPEED BRAKE (pause) SPEED BRAKE
NOTE (*): Bits 14 - 17, 19 – 22, and 24 - 29 will be set to zero. Not supported.
