Honeywell
MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896
SCALE: NONE
SIZE: A
DWG NO: 060-4314-150
REV:
SHEET
24
Rosemount
102EH2BH
Dual element, heated
1
EA
Rosemount
102EH2EB
Dual element, heated
1
EA
Rosemount
102JE2FG
Triple element, heated
1
EA
Rosemount
129H-500
Single element, unheated
1
EA
Rosemount
129G-500
Dual element, unheated
1
EA
1.10 Tools Requ ired
1.10.1 Crimping T ool - P1, P2, P3
Description
UM
QTY
Vendor Name & Part Number
Hand Crimping Tool
EA
1
Positronic Ind. 9507
Hand Crimping Tool
EA
1
Daniels
AFM8
Hand Crimping Tool
EA
1
Military
M22520/2-1
Hand Crimping Tool
EA
1
Astro
61517
1.10.2 Contact Po sitioner - P1, P2, P3
Description
UM
QTY
Vendor Name & Part Number
Contact Positioner, Socket P1
EA
1
Positronic Ind. 9502-3
Contact Positioner, Socket P1
EA
1
Daniels
K41 (for 22 to 28 AWG)
Contact Positioner, Socket P1
EA
1
Military
M22520/2-06
Contact Positioner, Socket P2
EA
1
Positronic Ind. 9502-5
Contact Positioner, Socket P2
EA
1
Daniels
K13-1 (20-24 AWG)
Contact Positioner, Socket P2
EA
1
Military
M22520/2-08
Contact Positioner, Pin P3
EA
1
Positronics
9502-4
Contact Positioner, Pin P3
EA
1
Daniles
K42 (22-28 AWG)
Contact Positioner, Pin P3
EA
1
Military
M22520/2-09
1.10.3 Insertion/R emoval Tool - P1, P2, P3
Description
UM
QTY
Vendor Name & Part Number
Removal Tool P1, P3
EA
1
Daniels
DRK 95-22M
Removal Tool P1, P3
EA
1
Military
M81969/8-02
Removal Tool P2 EA 1 Daniels DRK145
Insertion Tool P1, P3
EA
1
Daniels
DAK 95-22M
Insertion Tool P1, P3
EA
1
Military
M81969/8-01
Insertion Tool P2 EA 1 Daniels DAK145
Insertion/Removal Tool P1, P3
EA
1
Military
M81969/1-04
Insertion/Removal Tool P2
EA
1
Military
M81969/1-02
