Honeywell
MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896
SCALE: NONE
SIZE: A
DWG NO: 060-4314-150
REV:
SHEET
58
62
43
9
25
63
44
53
J1
Altitude Out
Signal Common
BIT Out
Analog Air Data Computer
EGPWS MK VI / MK VIII
(+)
(-)
Uncorrected
Barometric
Altitude
Baro Altitude Valid +28V
(+)
(-)
Temp. Input
Chassis Ground
+5V Excitation
500 ohm
Temperature
Probe
Analog-ADC.vsd
Cat 2
Uncorrected Baro Altitude
1
Vendor Model
ID
Altitude Out
Common
BIT Out
CIC 04077
0
J1-F
J1-G
J1-E
Collins ADS-65
3
J1-12
J1-13
J1-5
CIC 02702
4
J1-A
J1-B
J1-E
Honeywell AZ-241
11/12
2
J1A-63
J1A-11
(CGND)
J1A-12
Honeywell AZ-242
4
11/12
2
J1B-17
4
J1A-11
(CGND)
J1A-12
Honeywell AZ-648
11/12
2
J1-J
J1-G
J1-U
Honeywell AZ-800
3
11/12
2
J1A-78
J1A-10
(CGND)
J1A-34
Honeywell AZ-810
3
11/12
2
J1A-78
J1A-10
(CGND)
J1A-34
Honeywell AZ-252
11/12
2
J1A-17
J1A-10
(CGND)
J1A-34
NOTES:
1
The connector pin numbers given in the Table above are to the best knowledge of Honeywell EGPWS engineering. Please
contact the manufacturer’s customer service to confirm your installation.
2
ID 12 does not require an OAT input, instead a constant temperature of 25 deg C is assumed.
3
Honeywell AZ-810 should only be used as an analog source if it does not have a digital interface.
4
Honeywell AZ-242 with part numbers 4013242-708, -709, -710, -712, -713 and –742 have DC Altitude out at pin J1B-17. Part
numbers 4013242-709 and -711 have DC Altitude out at pin J1A-40.
