7.1.4 Equipment Identification
Provides equipment identification for maintenance reporting.
7.1.4.1 Equipment Identification Word (377)
Data: Discrete
Label (Octal): 377
Transmit Interval: 500 msec ± 10%
BIT NO DEFINITION
11 - 22 ID Code
Equipment ID code = 023 Hex for EGPWC.
23 - 29 Spare (set to zero)
7.1.5 Fault Summary Words (for Proline 4/21)
Provides fault diagnosis information.
7.1.5.1 Fault Diagnostic Word #1 (350)
Data: Discrete
Label (Octal): 350
Transmit Interval: 1000 msec
±
10%
BIT NO
DEFINITION (1= Failed)
11
ARINC 429 INPUT #1 FAILED
12
ARINC 429 INPUT #2 FAILED
13
ARINC 429 INPUT #3 FAILED
14
ARINC 429 INPUT #4 FAILED
15
ARINC 429 INPUT #5 FAILED
16
ARINC 429 INPUT #6 FAILED
17
ARINC 429 INPUT #7 FAILED
18
ARINC 429 INPUT #8 FAILED
19
ANALOG DC INPUT #1 FAILED
(future)
20
ANALOG DC INPUT #2 FAILED
(future)
21
ANALOG DC INPUT #3 FAILED
(future)
22
ANALOG DC INPUT #4 FAILED
(future)
23
ANALOG DC INPUT #5 FAILED
(future)
24
ANALOG DC INPUT #6 FAILED
(future)
25
ANALOG DC INPUT #7 FAILED
(future)
26
ANALOG SYNCHRO INPUT #1 FAILED
(future)
27
ANALOG SYNCHRO INPUT #2 FAILED
(future)
28
ANALOG SYNCHRO INPUT #3 FAILED
(future)
29
ANALOG SYNCHRO INPUT #4 FAILED
(future)
7.1.5.2 Fault Diagnostic Word #2 (351)
Data: Discrete
Label (Octal): 351
Transmit Interval: 1000 msec
±
10%
BIT NO
DEFINITION (1= Failed)
11
ANALOG SYNCHRO INPUT #5 FAILED
(future)
12
AC REFERENCE #1 FAILED
(future)
13
AC REFERENCE #2 FAILED
(future)
14
DC REFERENCE #1 FAILED
(future)
15
ADC RS232/RS422 INPUT FAILED
(future)
16
ADC RS232/RS422 OUTPUT FAILED
(future)
17
GPS RS232/RS422 INPUT FAILED
(future)
18
GPS RS232/RS422 OUTPUT FAILED
(future)
19
SUPPORT TASK FAILED
20
NVM FAULT
21
WATCHDOG TIMER FAULT
22
A/D FAIL FAULT
23
VOICE FAIL
24
DITS OUTPUT FAIL
25
TERRAIN DATABASE FAULT
26
FLASH FILE SYSTEM WRITE FAULT
27
DITS INPUT FAIL
28
VOICE DATABASE FAULT
29
SYSTEM OR MODE TASK FAULT
