Table 5.3.6.1-251 Honeywell Primus EPIC CDS/R, with binary Peaks Elevations MK VIII Only
Display Configuration Group 251
Function Value Reference section
Display Type Honeywell Integrated Primus Epic CDS/R (Control Display
System/Retrofit), with binary peaks elevations
Sweep Type Honeywell
Category 7, Options Select Group #1
TA&D Alternate Pop Up: False TA&D Alternate Pop Up: True
Auto Pop Up
Category 7 does not affect pop up logic. The display controls pop up,
therefore enable/disable of pop up is done via the display.
5.3.7
Category 7, Options Select Group #1
Peaks Enable: False Peaks Enable: True
Peaks Mode
Peaks Off Peaks On
5.3.7
Binary Peaks Elevations Yes - Data passed by ARINC 429, Labels 011 and 012
Manual select Selection is controlled by display
Manual deselect Deselection is controlled by display
Auto Range Yes 10NM
Moving Marker No
Overlay Page No
Display Priority Standard
Display bus type Honeywell picture bus
DISPLAY BUS #1 & #2
453TX_1 CONNECT TO:
A = J1-58
B = J1-59 Honeywell left/right interleaved picture bus to MFD and PFD 4.2.13.2
7.2
CONNECT TO:
Not supported for this display type
Display Input Control Group 250
CHANNEL
429_422RX_1 CONNECT TO: IOC #1 Bus
Format: ARINC 429 (High Speed) Fault Designation: IOC BUS 1
Bus Type: Basic
A = J2-37
B = J2-36 Data
FWC & GP discrete word Reference
6.2.48 Label
171 Sig. Bits
Format 1
Bits 15-18
Bits 25-28 Range
Type 1
2000NM
Discrete Signal Type
Basic Resolution
N/A Rate (ms)
100
CHANNEL
429RX_3 CONNECT TO: IOC #2 Bus
Format: ARINC 429 (High Speed) Fault Designation: IOC BUS 2
Bus Type: Basic
A = J2-41
B = J2-40 Data
FWC & GP discrete word Reference
6.2.48 Label
171 Sig. Bits
Format 1
Bits 15-18
Bits 25-28 Range
Type 1
2000NM
Discrete Signal Type
Basic Resolution
N/A Rate (ms)
100
Output 429 Bus Group 0
Channel Pins Comments
429TX_1 (Low Speed) A = J2-43
B = J2-42 Transmits (Section 7) Label sets: 7.1.1.x, 7.1.2.x, 7.1.3.x, 7.1.4.x, 7.1.5.x, and 7.1.6.x
429TX_2 (Low Speed) A = J2-26
B = J2-9 Transmits (Section 7) Label sets: 7.1.1.x, 7.1.2.x, 7.1.3.x, 7.1.4.x, 7.1.5.x, and 7.1.6.x
Integration Notes:
1. The EGPWS ARINC 429 Output Bus must be connected to the display.
2. Display channels 1 and 2 are multiplexed on ARINC 453 Bus 1.
3. This configuration will cause the GPWS INOP, TERRAIN INOP, and WINDSHEAR INOP lamps to turn on only at
the beginning of the EGPWS Self Test.
4. This display uses the following ARINC 429 labels from the EGPWS for annunciation’s:
Label 011/012 Upper/Lower Peaks Elevations – “xxx/xxx” on PFD and MFD.
Label 050 If bits 11-14 left range output from EGPWS does not match left MFD range (via label 171), then display
white “RANGE MISMATCH” on left PFD and MFD.
