MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 232
Table 5.3.6.1-249 Honeywell Primus EPIC CDS/R, (Integrated) with overlay
Peaks Elevations
MK VIII Only
Display Configuration Group 249
Function Value Reference section
Display Type Honeywell Primus EPIC CDS/R (Control Display System/Retrofit) with
overlay Peaks elevation
Sweep Type Honeywell
Category 7, Options Select Group #1
TA&D Alternate Pop Up: False TA&D Alternate Pop Up: True
Auto Pop Up
Category 7 does not affect pop up logic. The display controls pop up,
therefore enable/disable of pop up is done via the display.
5.3.7
Category 7, Options Select Group #1
Peaks Enable: False Peaks Enable: True
Peaks Mode
Peaks Off Peaks On
5.3.7
Manual select Selection is controlled by display
Manual deselect Deselection is controlled by display
Auto Range Yes 10NM
Moving Marker No
Overlay Page Yes, for Peaks Elevations only (located on lower right side of display)
Display Priority Standard
Display bus type Honeywell picture bus
DISPLAY BUS #1 & #2
453TX_1 CONNECT TO:
A = J1-58
B = J1-59 Honeywell left/right interleaved picture bus to MFD and PFD 4.2.13.2
7.2
CONNECT TO:
Not supported for this display type
Display Input Control Group 250
CHANNEL
429_422RX_1 CONNECT TO: IOC #1 Bus
Format: ARINC 429 (High Speed) Fault Designation: IOC BUS 1
Bus Type: Basic
A = J2-37
B = J2-36 Data
FWC & GP discrete word Reference
6.2.48 Label
171 Sig. Bits
Format 1
Bits 15-18
Bits 25-28 Range
Type 1
2000NM
Discrete Signal Type
Basic Resolution
N/A Rate (ms)
100
CHANNEL
429RX_3 CONNECT TO: IOC #2 Bus
Format: ARINC 429 (High Speed) Fault Designation: IOC BUS 2
Bus Type: Basic
A = J2-41
B = J2-40 Data
FWC & GP discrete word Reference
6.2.48 Label
171 Sig. Bits
Format 1
Bits 15-18
Bits 25-28 Range
Type 1
2000NM
Discrete Signal Type
Basic Resolution
N/A Rate (ms)
100
Output 429 Bus Group 0
Channel Pins Comments
429TX_1 (Low Speed) A = J2-43
B = J2-42 Transmits (Section 7) Label sets: 7.1.1.x, 7.1.2.x, 7.1.3.x, and 7.1.4.x
Integration Notes:
1. When interfacing to a single display controller configuration the bus must be connected to both EGPWS input
channels. This prevents the EGPWS from reporting an external bus fault on the second channel.
2. The ‘IOC BUS’ fault will be present only if both MG inputs have failed.
3. The Honeywell EFIS SG & MG provide Terrain display relay control.
4. The EGPWS ARINC 429 Output Bus must be connected to the display
5. This configuration will cause the GPWS INOP, TERRAIN INOP, and WINDSHEAR INOP lamps to turn on only at
the beginning of the EGPWS Self Test.
6. Display channels 1 and 2 are multiplexed on ARINC 453 bus 1.
7. This display uses the following ARINC 429 labels from the EGPWS for annunciations:
Label 050 If bits 11-14 left range output from the EGPWS does not match left MFD range (via label 171), then
display white “RANGE MISMATCH” on the left PFD and MFD.
