7.1.2.8 Body Angle of Attack—Left (224) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 224
Units: Degrees/180
Max. Range:
±
180 Degrees
Approx. LSB: 0.00549 Degree
Data Bits: 14 to 28 = 15
+ = Nose Up
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
7.1.2.9 Corrected Airspeed (242) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 242
Units: Feet/Second
Max. Range: 2048 Ft/Sec
Approx. LSB: 0.0625 Ft/Sec
Data Bits: 14 to 28 = 15
+ = Forward
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
7.1.2.10 Windshear Warning Threshold (331) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 331
Units: g’s
Max. Range: 0.0 40 -4.0 g’s
Approx. LSB: 0.00012207 g’s
Data Bits: 14 to 28 = 15
+ = N/A (always negative)
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
7.1.2.11 Corrected Longitudinal Acceleration (332) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 332
Units: g’s
Max. Range:
±
4.0 g’s
Approx. LSB: 0.00012207 g’s
Data Bits: 14 to 28 = 15
+ = Forward
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
Note: Longitudinal Acceleration is corrected by Cosine of Body Angle of Attack.
7.1.2.12 Raw Total Shear (362) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 362
Units: g’s
Max. Range:
±
4.0 g’s
Approx. LSB: 0.00012207 g’s
Data Bits: 14 to 28 = 15
+ = Headwind/Updraft
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
7.1.2.13 Corrected Normal Acceleration (364) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 364
Units: g’s
Max. Range:
±
4.0 g’s
Approx. LSB: 0.00012207 g’s
Data Bits: 14 to 28 = 15
+ = Up
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
Note: Normal Acceleration is corrected by Sine of Body Angle of Attack.
7.1.2.14 Computed Flight Path Angle (375) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 375
Units: Radians
Max. Range:
±
4.0 Radians
Approx. LSB: 0.00012207 Radians
Data Bits: 14 to 28 = 15
+ = Nose Up
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
7.1.2.15 Scaled Total Shear (376) – MKVIII EGPWS w/ Windshear only
LABEL (Octal) 376
Units: g’s
Max. Range:
±
4.0 g’s
Approx. LSB: 0.00012207 g’s
Data Bits: 14 to 28 = 15
+ = Headwind/Updraft
Sign Bit: 29
Pad Bits: 11 to 13
Transmit Interval (mSec): 100
±
20%
Data Type: 2’s Compliment Binary
SDI Bits: 9, 10
