MK VI MK VIII EGPWS Installation Design Guide
Proprietary notice on title page applies
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO: 060-4314-150 REV: SHEET 193
5.3.4 Category 4, Altitude Callouts
The following table provides identification of the Altitude Callouts Menu. Each entry in the ID column corresponds to a
particular menu selection. The Altitude Callouts menu ID’s 0 through 12 consist of standard callouts. Selecting ID 0 – 12
will result in the callouts listed being enunciated.
Smart 500 activation is reflected by a “500” callout being spoken at the end of the selected callout menu sequence in the
Long Level 1 Self-Test. In addition, the Callout menu ID number and the “Smart Callout Selected” configuration
message, will both be given during level 3 Self-Test and in the RS232 Present Status display.
Table 5.3.4: Altitude Callouts
ID MENU
Smart
Callout
Software
Effectivity
EGPWS
Selected MKVI MK VIII
0
MINIMUMS-MINIMUMS,
“Smart 500”, 200, 100, 50, 40, 30, 20 ,10
True -020 X X
1
MINIMUMS-MINIMUMS,
“Smart 500”, 200
True -020 X X
2
MINIMUMS-MINIMUMS,
“Smart 500”, 100, 50, 40, 30, 20 ,10
True -020 X X
3
MINIMUMS-MINIMUMS,
“Smart 500”
True -020 X X
4 1
MINIMUMS-MINIMUMS,
200, 100, 50, 40, 30, 20 ,10
False -020 X X
5 1
MINIMUMS-MINIMUMS,
200
False -020 X X
6 1
MINIMUMS-MINIMUMS,
100, 50, 40, 30, 20 ,10
False -020 X X
7 1
(no callouts)
False -020 X X
8 1
MINIMUMS-MINIMUMS
False -020 X X
9
MINIMUMS-MINIMUMS,
500, 200, 100, 50, 40, 30, 20 ,10
False -020 X X
10
MINIMUMS-MINIMUMS,
500, 200
False -020 X X
11
MINIMUMS-MINIMUMS,
500, 100, 50, 40, 30, 20 ,10
False -020 X X
12
MINIMUMS-MINIMUMS,
500
False -020 X X
13
MINIMUMS,
1000, 500, 400, 300, 200, 100, 50, 40, 30, 20, 10
False -020 X X
14 1
MINIMUMS-MINIMUMS,
100
False -020 X X
15 1
MINIMUMS-MINIMUMS,
200, 100
False -020 X X
100 2 Above Field Callout “500” False -020 X X
101 2 Above Field Callout “500 Above” False -020 X X
1 Compliance with TSO-C151a requires a "500" callout. These IDs cannot be used on installations requiring compliance with TSO-C151a unless
there is an alternate source of the "500" callout.
2 This ID provides Above Field Callout. Geometric altitude and runway database are used to calculate the height above field. If this ID is selected
TA&D and TCF must be enabled (MK VI and MK VIII installations cannot select Category 6 ID 2).
Note: Selecting an Altitude Callout ID without a minimums callout can be accomplished by leaving the Decision Height (DH) input discrete open.
