HEIDENHAIN iTNC 530 405
15.13 D
A
TUM IN ONE AXIS (Cy
c
le 41
9, DIN/ISO:
G41
9
)
 Traverse direction Q267: Direction in which the
touch probe is to approach the workpiece:
-1: Negative traverse direction
+1: Positive traverse direction
 Number in table Q305: Enter the number in the
datum or preset table in which the TNC is to save the
coordinate. If you enter Q305=0 and Q303=1, the
TNC automatically sets the display so that the new
datum is on the probed surface. If you enter Q305=0
and Q303=0, the TNC writes the coordinate in line 0
of the datum table. Input range 0 to 99999
 Datum number in table Q305: Enter the number in the
datum or preset table in which the TNC is to save the
coordinate. If you enter Q305=0, the TNC
automatically sets the display so that the new datum
is on the probed surface. Input range 0 to 99999
 New datum Q333 (absolute): Coordinate at which the
TNC should set the datum. Default setting = 0. Input
range -99999.9999 to 99999.9999
 Measured-value transfer (0, 1) Q303: Specify
whether the determined datum is to be saved in the
datum table or in the preset table:
-1: Do not use. Siehe „Saving the calculated datum”,
Seite 360
0: Write determined datum in the active datum table.
The reference system is the active workpiece
coordinate system.
1: Write determined datum in the preset table. The
reference system is the machine coordinate system
(REF system).
Beispiel: NC blocks
5 TCH PROBE 419 DATUM IN ONE AXIS
Q263=+25 ;1ST POINT 1ST AXIS
Q264=+25 ;1ST POINT 2ND AXIS
Q261=+25 ;MEASURING HEIGHT
Q320=0 ;SET-UP CLEARANCE
Q260=+50 ;CLEARANCE HEIGHT
Q272=+1 ;MEASURING AXIS
Q267=+1 ;TRAVERSE DIRECTION
Q305=0 ;NO. IN TABLE
Q333=+0 ;DATUM
Q303=+1 ;MEAS. VALUE TRANSFER
