Mounting the rack slides – Grass Valley PVS Series System Guide v.4.0 Dec 10 200 User Manual
Page 274
Appendix C
Rack Mounting Information and Rear Panel Drawings
274
Profile XP System Guide
July 27, 2001
Mounting the Rack Slides
Choose the proper set of rail mounting holes on the rack. Notice that the hole spacing
can vary with the rack type. When mounting the slides in racks with EIA spacing,
make sure that the slides are attached to the 0.5-inch spaced holes.
1.250 in
MIL STD 189
“UNIVERSAL” SPACING
0.500 in
0.625 in
1.250 in
1.250 in
0.625 in
