Audio board connector
July 27, 2001
Profile XP System Guide
269
Audio board connector
The Audio Board accepts 16 channels of digital audio input and provides 16 channels
of digital audio output via a 80-pin connector on the rear panel. The cable to this
connector is from the Profile Audio Chassis (PAC) or from the XLR/BNC 216 Digital
Audio Breakout Box.
Female
0624-36
1
40
80
41
