Dolby Decode/Encode
Imagestore 750 User Manual
Page 342
Miranda Technologies Inc.
Decode and Encode Combinations
There can be a total of up to four Dolby decoder/encoder modules installed
within an Imagestore 750. The module combinations cover use cases for
decode of Dolby E, and encode of Dolby E or Dolby Digital.
Product codes cover various user cases by allowing combinations to be built
up. The table below summarises some of the possible encode/decode use-
case combinations:
ID
Encode / Decode
Combination
Dolby E
Decoders
Dolby E
Encoders
Dolby
Digital
Encoders
1
E encode
1, 2, 3 or 4
2
Digital encode
1, 2, 3 or 4
3
E decode
2 or 4
4
E decode + E encode
2
1 or 2
5
E decode + Digital encode
2
1 or 2
The diagrams below depict possible Dolby decode/encode combinations from
the table above.
