Imagestore 750 User Manual
Front Panel Operations
Miranda Technologies Inc.
Page 137
Delete
Deletes the displayed command line.
Insert After
Inserts a new command after the displayed line.
Output from GPI
A GPI port may used as an output to trigger external devices and its active
status, (on), is defined by the output being internally pulled to ground.
Further details concerning this electrical interface are contained in the
Installation section below.
All GPIs (1-16) may be assigned as a GPI Output with a condition assigned
whether it is set on or off, for example GPI Out x On or GPI Out x Off .
Create a GPI Output
To create a GPI output, display the relevant GPI then press enter. If the GPI
is unused > None < will be displayed on the front panel. Press enter again
then using the joystick arrows ⊳ display the command to be added to the
GPI Output and press enter to add it. Only a single function may be added to
a GPI Output.
The options are:
> None <
Mixer At A
Mixer At B
DSK1 FTB Off
DSK1 FTB On
DSK2 FTB Off
DSK2 FTB On
DSK3 FTB Off
DSK3 FTB On
DSK4 FTB Off
DSK4 FTB On
DSK1 Key Off
