Audio Mix Files Imagestore 750 User Manual
Page 234 Miranda Technologies Inc.
AES_O_P11_R 11 Right
AES_O_P12_L 12 Left
AES_O_P12_R 12 Right
AES_O_P13_L 13 Left
AES_O_P13_R 13 Right
AES_O_P14_L 14 Left
AES_O_P14_R 14 Right
AES_O_P15_L 15 Left
AES_O_P15_R 15 Right
AES_O_P16_L 16 Left
AES_O_P16_R 16 Right
METER_1 to METER_64 Metering Points 1 - 64
DELAY1_O_1 to 16 Output to Delay Bank 1 - 16
DELAY2_O_1 to 16 17 - 32
DELAY3_O_1 to 16 33 - 48
DELAY4_O_1 to 16 49 - 64
DELAY5_O_1 to 16 65 - 80
DELAY6_O_1 to 16 81 - 96
DELAY7_O_1 to 16 97 - 112
DELAY8_O_1 to 16 113 –
128
AUDIO_MODULE1_O_P1_L to
AUDIO_MODULE1_O_P8_R
Dolby/Up-Mix Output
(Module 1)
1 - 16
AUDIO_MODULE2_O_P1_L to
AUDIO_MODULE2_O_P8_R
Dolby/Up-Mix Output
(Module 2)
17 - 32
AUDIO_MODULE3_O_P1_L to
AUDIO_MODULE3_O_P8_R
Dolby/Up-Mix Output
(Module 3)
33 - 48
AUDIO_MODULE4_O_P1_L to
AUDIO_MODULE4_O_P8_R
Dolby/Up-Mix Output
(Module 4)
49 - 64
Mixfile Mapping
The standard Imagestore 2 mixfiles (is23.mix and is23eply.mix) assign the
following AES Input pins:
•
AES_1
±
and AES_2
±
A input Pair 1 and Pair 2
•
AES_3
±
and AES_4
±
VO1 Pair1 and Pair 2
•
AES_5
±
and AES_6
±
B input Pair 1 and Pair 2
AES Output pins:
•
AES_1
±
and AES_2
±
PVW output Pair 1 and Pair 2
•
AES_3
±
and AES_4
±
PGM output Pair 1 and Pair
