Imagestore 750 User Manual Installation
Miranda Technologies Inc. Page 279
o Configured as Input or Output
o 115.2K baud
o 1 start bit, 8 data bits, 1 stop bit
o No parity
•
Two extra RS232 port for future use.
The table below shows pin-outs for the GPIO 44-way D-type connector.
Pin No Signal Name
1 LTC-
2 LTC_GND
3 TOTAL_DC_FAIL
4 GPIO_15
5 GPIO_13
6 GPIO_11
7 GP_+5V
8 GP_+12V
9 GPIO_8
10 GPIO_6
11 GPIO_4
12 GPIO_2
13 GP_GND
14 RS232B_TX (reserved for future use)
15 RS232B_RTS (reserved for future use)
16 RS485/1+
17 RS485/1-
18 RS485/2+
19 RS485/2-
20 RS485/3+
21 RS485/3-
22 RS485/4+
23 RS485/4-
