Imagestore 750 User Manual Standard Mixfiles
Miranda Technologies Inc. Page 311
undesired behaviour or silence. The automation commands required to set the
Imagestore to this mix mode are as follows:
PGM input:
j01514 j01524:
PST input: j03514: j03524:
The ‘jg’ automation command should now be used to set up the shuffles in
the matrix. First it is prudent to clear any existing shuffles to prevent any
undesired effects:
PGM input:
jg100: jg110: jg120: jg130:
PST input: jg300: jg310: jg320: jg330:
Next the crosspoints in the matrix are set. The following commands set the
shuffle configuration for the diagram below, giving left to left, left to centre,
right to right, and right to centre.
PGM input:
jg105: jg116:
PST input: jg305: jg316:
