The connector type is 75Ω BNC terminated internally. All video inputs must
be locked to this reference input. The reference must therefore be the same
frame rate as the video SDI inputs.
Imagestore 750 operating in HD mode may use a tri-level or bi-level sync.
Imagestore 750 operating in SD mode, may only use a bi-level sync.
LAN 1-2
These are used to connect to up to two local network switches.
Note: It is recommended that both LAN ports are connected, ideally to
separate switches as the ports are ‘bonded’ together (in
software) to achieve Ethernet redundancy on the same IP
address.
Pin No. Signal Name RJ45
1 TDP
2 TDN
3 RDP
4 NC
5 NC
6 RDN
7 NC
8 NC
Connector type: 8 pin RJ45.
Each of the LAN ports has two integral LED indicators.
Green LED indicates 100Mbps speed
Yellow LED indicates active network link.
