RCP Operations Imagestore 750 User Manual
Page 212 Miranda Technologies Inc.
The DSK 3 button will remain illuminated whilst the image in on-air unless
the control of DSK3 and DSK4 has been disabled using “Setup Menu,
DSK34, 12I”
,
DSK 4
DSK4 is the forth keying layer. See controls for DSK 1. DSK 4 can only be
used if enabled using “Setup Menu, DSK34, 1234”,
The DSK 4 button will remain illuminated whilst the image in on-air unless
the control of DSK3 and DSK4 has been disabled using “Setup Menu,
DSK34, 12I”
,
Take
Pressing the Take button will activate all armed DSK’s (DSK1 and/or DSK2
and/or DSK3 and/or DSK4) and the Mixer, sending the transition to air.
Black and Silence
Pressing the Black and Silence button will send the total output of Key
Layer 0 and 1 to black. The transition types are:
•
Cut to Black
•
Cut from Black
•
Fade to Black
•
Fade from Black
