Imagestore 750 User Manual RCP Operations
Miranda Technologies Inc. Page 185
RCP Operations
Introduction
This section provides a basic introduction to the Imagestore 750 Remote
Control Panel (IS300-RCP) and describes the features and facilities provided
by the unit. Note that keyer control can be configured for two possible
modes:
•
Operation of DSK1 and DSK2 – (standard RCP)
•
Operation of all four keying layers – (modified RCP with DSK3 and
DSK4 controlled via the keypad)
The two RCP configuration options, for control of DSK1/DSK2 or
DSK1/DSK2/DSK3/DSK4 respectively, are shown below. These need to be
matched via the DSK CONTROL menu (see page 189).
